TK 45-2476
THERMO KING - Controller boards & EPROM - TK 45-2476
Part number
TK 45-2476
Designation
Controller DSR-III
Specifications
Platform 1 + 2 . . . 24V
12V by changing the fuses
12V by changing the fuses
Original number
TK . . . 2E13471G06 / 45-2476
Refrigerant
-
OEM number
THERMO KING . . . 45-2476
Note
This controller must be updated with the latest firmware and the unit configuration loaded before use.
Firmrare and configurations are different between DSR-III and DSR-3.1
Firmrare and configurations are different between DSR-III and DSR-3.1
Application list
THERMO KING . . . Electric units
. . . . . . . . . . . . . . . . . . . . . E-200 series . . . Spectrum
. . . . . . . . . . . . . . . . . . . . . E-400e series, E-500e series, E-600e series
THERMO KING . . . Direct Drive units
. . . . . . . . . . . . . . . . . . . . . V-200 series, V-300 series . . . Spectrum
. . . . . . . . . . . . . . . . . . . . . V-400 series, V-500 series, V-600 series
. . . . . . . . . . . . . . . . . . . . . V-400x series, V-500x series, V-600x series
. . . . . . . . . . . . . . . . . . . . . V-700 series, V-800 series
. . . . . . . . . . . . . . . . . . . . . V-1000 series
Spare parts:
TK 42-0589 . . . Relay board
THERMO KING . . . Electric units
. . . . . . . . . . . . . . . . . . . . . E-200 series . . . Spectrum
. . . . . . . . . . . . . . . . . . . . . E-400e series, E-500e series, E-600e series
THERMO KING . . . Direct Drive units
. . . . . . . . . . . . . . . . . . . . . V-200 series, V-300 series . . . Spectrum
. . . . . . . . . . . . . . . . . . . . . V-400 series, V-500 series, V-600 series
. . . . . . . . . . . . . . . . . . . . . V-400x series, V-500x series, V-600x series
. . . . . . . . . . . . . . . . . . . . . V-700 series, V-800 series
. . . . . . . . . . . . . . . . . . . . . V-1000 series
Spare parts:
TK 42-0589 . . . Relay board
