TK 45-2190
THERMO KING - Controller boards & EPROM - TK 45-2190
Part number
TK 45-2190
Designation
Controller DSR-II
Specifications
Platform 1 . . . 12V
24V by changing the fuses
24V by changing the fuses
Original number
TK . . . 1E16173G03 / 45-2190
replace :
TK . . . 1E16173G01 / 45-2073
TK . . . 1E16173G02 / 45-2074
TK . . . 1E16173G04 / 45-2191
replace :
TK . . . 1E16173G01 / 45-2073
TK . . . 1E16173G02 / 45-2074
TK . . . 1E16173G04 / 45-2191
Refrigerant
-
OEM number
THERMO KING . . . 45-2190
Note
This controller must be updated with the latest firmware and the unit configuration loaded before use.
Application list
THERMO KING . . . Electric units
. . . . . . . . . . . . . . . . . . . . . B-100 series . . . before 12.13
THERMO KING . . . Direct Drive units
. . . . . . . . . . . . . . . . . . . . . V-100 series . . . before 10.13 / serial 0001168177
. . . . . . . . . . . . . . . . . . . . . V-200 series . . . before 02.13 / serial 0001154424
. . . . . . . . . . . . . . . . . . . . . V-300 series . . . before 03.13 / serial 0001155094
. . . . . . . . . . . . . . . . . . . . . V-700 series . . . before 12.13
THERMO KING . . . Electric units
. . . . . . . . . . . . . . . . . . . . . B-100 series . . . before 12.13
THERMO KING . . . Direct Drive units
. . . . . . . . . . . . . . . . . . . . . V-100 series . . . before 10.13 / serial 0001168177
. . . . . . . . . . . . . . . . . . . . . V-200 series . . . before 02.13 / serial 0001154424
. . . . . . . . . . . . . . . . . . . . . V-300 series . . . before 03.13 / serial 0001155094
. . . . . . . . . . . . . . . . . . . . . V-700 series . . . before 12.13
