Einbausätze Kompressoren - TGE . . . (UY_, UZ_) . . . 11.16 > - 19 363 238
Artikelnummer
19 363 238
Bezeichnung
Kompressoreinbausatz
Spezifizierungen
SD5H14 / SD5L14
SD7H15 / SD7L15
QP-13 / TM-13
QP-15 / TM-15
QP-16 / TM-16
SD7H15 / SD7L15
QP-13 / TM-13
QP-15 / TM-15
QP-16 / TM-16
Original Nummer
VW2C.038
Kältemittel
-
OEM Nummer
---
Notiz
For use with :
Que . . . QP-13 / Valeo . . . TM-13
Que . . . QP-15 / Valeo . . . TM-15
Que . . . QP-16 / Valeo . . . TM-16
Clutch P8 . . . ø 119 mm
Compressor speed . . . rpm
Sanden . . . SD5H14 / SD5L14, SD7H15 / SD7L15
Clutch P7 or P8 . . . ø 119 mm
And any compressor with the same mounting size and gauge line
Que . . . QP-13 / Valeo . . . TM-13
Que . . . QP-15 / Valeo . . . TM-15
Que . . . QP-16 / Valeo . . . TM-16
Clutch P8 . . . ø 119 mm
Compressor speed . . . rpm
Sanden . . . SD5H14 / SD5L14, SD7H15 / SD7L15
Clutch P7 or P8 . . . ø 119 mm
And any compressor with the same mounting size and gauge line
Anwendungen Liste
MAN . . . TGE . . . (UY_,UZ_) . . . 11.16 > . . . FWD & 4x4
. . . . . . . . . 2.0 TDI . . . Engine DAUB [Euro 6] . . . 4 / 1968 cm³ . . . 102 HP . . . 11.16 -
. . . . . . . . . 2.0 TDI . . . Engine DAUA [Euro 6] . . . 4 / 1968 cm³ . . . 140 HP . . . 11.16 -
. . . . . . . . . 2.0 BiTDI . . . Engine DAVA [Euro 6] . . . 4 / 1968 cm³ . . . 177 HP . . . 11.16 -
Compatible with 4x4
Compatible with automatic gearbox
For vehicles without MAN option ''632IL'' (second Compressor factory installed)
MAN option [KFG] module with [631JD] software must be ordered to allow the unit to deactivate the STOP & START.
According to MAN, there a six different crankshaft pulleys,
all with part number 04L.105.251 but final letter can be ''E'' / ''F'' / ''G'' / ''L'' / ''J'' / ''K''
If the letter is not ''K'', one pulley 19 361 437 PV MUST be ordered and replaced
ONLY With A/C
MAN . . . TGE . . . (UY_,UZ_) . . . 11.16 > . . . FWD & 4x4
. . . . . . . . . 2.0 TDI . . . Engine DAUB [Euro 6] . . . 4 / 1968 cm³ . . . 102 HP . . . 11.16 -
. . . . . . . . . 2.0 TDI . . . Engine DAUA [Euro 6] . . . 4 / 1968 cm³ . . . 140 HP . . . 11.16 -
. . . . . . . . . 2.0 BiTDI . . . Engine DAVA [Euro 6] . . . 4 / 1968 cm³ . . . 177 HP . . . 11.16 -
Compatible with 4x4
Compatible with automatic gearbox
For vehicles without MAN option ''632IL'' (second Compressor factory installed)
MAN option [KFG] module with [631JD] software must be ordered to allow the unit to deactivate the STOP & START.
According to MAN, there a six different crankshaft pulleys,
all with part number 04L.105.251 but final letter can be ''E'' / ''F'' / ''G'' / ''L'' / ''J'' / ''K''
If the letter is not ''K'', one pulley 19 361 437 PV MUST be ordered and replaced
ONLY With A/C
